140 Rockwell Automation Publication 1789-UM002K-EN-P - January 2015

Chapter 7 Develop External Routines

INTEGER Example

C Declaration

extern "C" __declspec(dllexport) int SomeCalculation(EXT_ROUTINE_CONTROL* pERCtrl,

int Val)

XML Declaration

<EntryPoint> SomeCalculation </EntryPoint>

<Description>Do an important calculation</Description>

<Signature>int SomeCalculation (EXT_ROUTINE_CONTROL* pERCtrl,

int Val)</Signature>

</Routine>

Software Declaration
