Rockwell Automation Publication 1789-UM002K-EN-P - January 2015 81

Communicate with Serial Devices Chapter 4

Your SoftLogix Chassis Monitor looks like this example.

Step 2: Configure the Serial Port of the Controller in the Project

Complete these steps to configure the controller in your project.

1. Open a project in the Logix Designer application and add the controller to

the I/O Configuration folder.

Refer to

Step 3: Configure the Controller in the Logix Designer

Application Project on page 32.

2. From the Edit menu, choose Controller Properties.
