Allen-Bradley SoftLogix 5800 User Manual

68 Rockwell Automation Publication 1789-UM002K-EN-P - January 2015
Chapter 3 Communicate with Devices on an Ethernet Network
Example 2: Send Messages
over the EtherNet/IP
Network
In the following example, the SoftLogix controller can send messages to the other
devices on the EtherNet/IP network.
Item Description
1 Ethernet switch
2 Firewall/router
3 ControlLogix chassis with controller and Ethernet module
4 PanelView terminal
5 Personal computer running RSLinx software and the Logix Designer application
6 Ethernet switch
7 FLEX I/O system with Ethernet adapter
8 ControlLogix gateway
9 To ControlNet network
10 To DeviceNet network
11 To DH+ network
12 SoftLogix 5800 controller
2
1
6
9
10
11
3
5
4
7
8
12
