Rockwell Automation Publication 1789-UM002K-EN-P - January 2015 257

Appendix F

Status Indicators

This appendix describes the status indicators for the SoftLogix 5800 controller

and its associated modules.

SoftLogix Controller Status

Indicators

The controller has these status indicators.

Topic Page

SoftLogix Controller Status Indicators 257

SoftLogix EtherNet/IP Module Status Indicators 259

Indicator Description

1 Module display status

2 Mode display

3Key switch

Default Chapter5
