Rockwell Automation Publication 1789-UM002K-EN-P - January 2015 203

Communicate with Devices on a ControlNet Network Appendix B

8. Click OK.

IMPORTANT

The virtual backplane driver must be installed via RSLinx software

before you can download a project to the SoftLogix controller. Even if

you plan to remotely program the controller over a ControlNet or

Ethernet network, you must add the virtual backplane driver via

RSLinx software. If you do not, persistent storage will not function and

when you restart the computer, the controller will come up with

cleared memory (the program will not get reloaded).
