Rockwell Automation Publication 1789-UM002K-EN-P - January 2015 235

Communicate with Devices on a ControlNet Network Appendix B

In the following illustration, the ControlLogix controller can remotely access a

PanelView™ terminal over a ControlNet network. The SoftLogix Chassis

Monitor resides on the computer. A SoftLogix controller is not required for the

gateway—you only need a 1784-PCICS card for each ControlNet network.

Item Description

1 ControlLogix controller

2 ControlNet network 1

3 ControlNet network 2

4 PanelView terminal

5 The SoftLogix Chassis Monitor has two 1784-PCICS cards installed - one for each

ControlNet network.
