8. Operation Screens
8-49
CURRENT
SAMPLING
INTERVAL
FORCE
SAMPLING
INTERVAL
Current
measure-
ment
Displace-
ment
measure-
ment
Force/
external
measure-
ment
TIME WAVE
DECIMATION
200us
*1
100us
*1
Yes Yes/No No All
settings
100us, 200us and
1000us are the same
as setting. 20us,
50us and 500us
become 100us.
200us
500us 100us, 500us and
1000us are the same
as setting. 20us,
50us and 200us
become 100us.
20us
*1
50us
*1
100us
100us No No - 100us, 200us,
500us, and 1000us
are the same as
setting. 20us and
50us become 100us.
200us 200us and 1000us
are the same as
setting. 20us, 50us,
100us, and 500us
become 200us.
500us 500us and 1000us
are the same as
setting. 20us, 50us,
100us, and 200us
become 500us.
200us
*1
100us
*1
200us and 1000us
are the same as
setting. 20us, 50us,
100us, and 500us
become 200us.
200us
500us 500us and 1000us
are the same as
setting. 20us, 50us,
100us, and 200us
become 500us.
*1: Also refer to CURRENT SAMPLING INTERVAL and FORCE/ EXTERNAL
SAMPLING INTERVAL in Chapter 8, “n-2. SETUP SYSTEM (2) Screen.”
(5) UNITS
Select whether to add a unit to the save data or not.
OFF: Not added
ON: Added
