4 Introducing LivePremier™
Before setting up the LivePremier for the first time, please read through all of the documentation to become
familiar with its powerful features. The LivePremier can be used in multiple configurations, which results in
a versatile video production tool for live event staging and fixed installation applications. LivePremier is not
limited by pixel canvas size and can process up to 120 Megapixels throughput at 10 bits 4:4:4 @60Hz.
4.1 LivePremier – Modular architecture
LivePremier is designed to be modular. Input and Output cards can be replaced and every card is composed
of four identical slots. Fixed models have been created for users looking for stable preconfigured units
(Freelance, Rental or Staging). All other units are considered Custom versions.
The LivePremier product range includes five fixed models and two customizable models:
Aquilon Models
RS
alpha
RS1
RS2
RS3
RS4
C
C+
4K60p inputs
8
16
16
24
24
0 to 16
4 to 24
4K60p outputs
4
8
12
12
16
0 to 16
4 to 20
Max 4K60p PGM outputs
4
4
+ 4 Aux
8
+ 4 Aux
8
+ 4 Aux
12
+ 4 Aux
8
+ 8 Aux
12
+ 8 Aux
Max DL/2K60p mixing layers
8
8
16
16
24
up to 16
up to 24
Simultaneous 4K image
channels
12
12
12
24
24
up to 12
up to 24
Rack units
4RU
4RU
4RU
5RU
5RU
4RU
5RU
Table 1 - LivePremier family
A fixed unit that has been modified becomes a Custom unit.
For more information on input/output cards, see 4.4 Input / Output cards page 18.
