4.4 Input / Output cards
Available cards
Input and output cards can be replaced on field and every card is composed of four identical connectors.
Each connector represents one input/output and supports formats up to 4K 60Hz 4:4:4.
Table 2 - LivePremier optional input and output cards
*12G-SFP input and output cards can receive SFP modules either for SDI over Fiber of for SDI over IP / SMPTE.
For more information, visit www.analogway.com or contact Analog Way support.
Change an input / output card
Warning: - Input / output cards are NOT hot swappable. The unit must be turned off and disconnected from power.
- Input cards cannot be used as output cards and vice versa.
- Do not force cards in places other than slots specified in Fig. 2 - LivePremier rear panel (Aquilon RS4) page 17.
- Do not remove cards other than input and output cards.
Installation rules: - Cards must be installed from top to bottom.
- LivePremier units must have 2, 4 or 6 input cards (no odd numbers).
Tip: Input and output cards have different size and colors. Note that output cards are black.
Tools required: one cross-head screwdriver.
1. Turn off the LivePremier unit and disconnect all power supply.
2. Locate the card to change.
3. Loosen the screws on both sides of the card, use the screwdriver if needed.
4. Carefully place the card in the box provided.
5. Put the new card in place, keep a straight axis and pay attention to the rails.
6. Push the new card until mechanical stop to ensure the connection is correct.
7. Tighten the screws on both sides of the card, use the screwdriver.
8. Reconnect the power supplies and turn on the LivePremier unit.
9. Open the WebRCS to check the new card is correctly installed. If needed, update the LivePremier
unit.
