Input signal
In Inputs, select an input. In Signal, the following settings are displayed:
Setting name
Description / Setting selection
Label
Rename the Input
Signal Type
Auto, YUV, RGB Full (0-255) or RGB Limited (16-235).
HDCP
None*; Default; HDCP 1.x Only or HDCP 1.x and 2.x
Black
On/Off toggle. Display Black in place of the selected input.
Freeze
On/Off toggle. Freeze the input (useful for Color correction, Cropping or Keying).
*Disabling HDCP reduces possible problems when the content is not fully HDCP compliant. When input HDCP is disabled, HDCP-
protected inputs are not displayed.
Recommendation: Always use high quality cables to prevent connection and bandwidth errors when using HDCP.
Input pattern
When enabled, a pattern overrides any input signal. Most patterns offer adjustment to isolate a
particular color for easier troubleshooting and calibration.
In Inputs, select an input. In Pattern / Raster, the following settings are displayed:
Setting name
Description / Setting selection
Patterns
Enable
On/Off toggle. Display the pattern in input
Patterns
Select the pattern to display
Note: For more information on pattern types, see 7.4.1 Patterns page 43.
Input adjustment (image correction)
In Inputs, select an input. In Adjustments, the following settings are displayed:
Setting name
Description / Setting selection
Colorimetry
Adjust Brightness, Contrast, Saturation and Hue
User Gain
Adjust Red, Green and Blue
Sharpness
Low, Medium or High
PullDown
2:2 and 3:2 On/Off toggles
