APPENDICES
Appendix A. LivePremier control options
The WebRCS is the main controller for LivePremier. In addition, it can be used with other control options.
LivePremier units are compatible with the Analog Way Shot Box² and Control Box² and also with Companion
installed on a Stream deck.
Shot Box²
Control Box²
Stream deck + Companion
Tip: A new controller specifically designed for LivePremier is currently under development.
A.a. Use the Shot Box² and Control Box² with LivePremier
Analog Way Shot Box² and Control Box² can be used to recall Memories and trigger transitions.
To use these controllers:
1. Connect the controller directly to the LivePremier unit via USB ports.
2. On the unit front panel, go to Control > Controllers:
a. Go to Status to check the detected Controllers.
b. Enable Identify to display ID on the controller (1 or 2).
3. Select the controller to open its settings:
Controller setting
Description
Enable
Enable or disable the controller
Backlight
Set the keyboard brightness (in %)
Mode*
Choose to recall Screen Memories or Master Memories
Screen*
Choose the Screen
Destination*
Choose to interact with Program or Preview
Autoscale
Enable to rescale Memory to applied Screen canvas size
Take on load
Enable to automatically trigger the transition when loading a Memory on Preview
Reset
Reset the controller configuration
*only available with the ShotBox².
4. Use the keys of the controller to recall Memories and trigger transitions.
A.b. Use the Stream deck with Companion with LivePremier
Companion is a software that transforms the Elgato Stream deck as a shot box that can be used with
LivePremier units. For more details, please refer to Companion documentation.
