Analog way LivePremier Series User Manual

www.analogway.com
17
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
USER MANUAL
4.2 Front panel
It is composed of one OLED display, two USB ports, three buttons (Power, Enter and Exit) and a coder.
The front panel can be used for admin features or information (Firmware update, Network settings,
Import/Export configuration, Factory Reset and Status check).
Fig. 1 - LivePremier 4RU and 5RU front panels
The front panel displays information such as device IP address, firmware version, or CPU and GPU status.
- Press the Next/Status button to wake the display and show device information.
- Press again to cycle through the next pages.
The display automatically goes off after 3 minutes of inactivity.
4.3 LivePremier rear panels
Fig. 2 - LivePremier rear panel (Aquilon RS4)
Inputs
Outputs
