USER MANUAL

16 Multiviewers

Tip: Go to Multiviewers after all pre-configurations are set.

A Multiviewer is an output displaying a user customizable selection of Widgets as display resources. A Widget

works like a layer and can display a program, preview, input, image or timer. One Multiviewer can display up

to 24 Widgets.

In Multiviewers, set the Multiviewers layout and Widgets. This menu displays one or two Multiviewers

screens, depending on what is set in Preconfig > Multiviewers.

Note:

- Go to Preconfig > Multiviewers to enable One Multiviewer or Two Multiviewers.

-Got to Setup Multiviewers to set the Label, Signal parameters, Patterns and Image correction.

16.1 Tips and recommendations

- Widgets cannot be placed on top of each other (overlap error).

- The same source cannot be used in more than one widget per Multiviewer.

- Two widgets using the same source in both Multiviewers are displayed at the same resolution (smallest

widget).

16.2 Multiviewers menu interface

The menu Multiviewers behaves much like the menu Screens:

- Sources on the left panel: Inputs; Images; Timers and Screens.

- Widget letter icons and Bottom bar icons.

- Widget properties and Memories on the right panel.

Note: There are no transition or Program/Preview features in Multiviewers.
