Anritsu MS9710C - 9.1 ALIN [Auto Alignment]

Section 9 Details on Device Messages
9-2
9.1 ALIN [Auto Alignment]
■ Function
With the measuring light radiated, executes auto alignment to create alignment
position data. When auto alignment is complete, bit 4 (execution complete bit) of
the extended event register (ESR2) is set to 1.
Header Program Query Response
ALIN ALIN n ALIN ? m
■ • Value of n
n = 0: Specify the alignment position data as the default.
= 1: Execute auto alignment to create alignment position data.
= 2: Terminate auto alignment forcibly.
■ • Value of m
m = 0: Normal termination of waveform calibration
= 1: Wavelength calibration is in process.
= 2: Wavelength calibration has been interrupted due to an insufficient light level.
= 3: Wavelength calibration has been interrupted due to any other fault.
