Anritsu MS9710C - LLV [Linear Scale]; LOFS [Level Offset]

9-45
9.47 LLV [Linear Scale]
■ Function
Selects a linear scale as a level scale and sets a scale value.
Header Program Query Response
LLV LLV l LLV ? l
■ Value of l
When A, B, or A & B is selected by TSL (Trace Select)
l is a scale value. Specify a unit and a value, 1 to 4, or specify a value with its
unit fixed at mW.
Unit .................. W, MW, UW, NW, PW
Data range ........ 1PW ≤ 1 ≤ 1W
When A-B or B-A is selected by TSL (Trace Select) and a normalize display
mode is set
l is a scale value. Specify a unit and a value, 1 to 3. The unit may be omitted.
Unit .................. PCT
Data range ........ 1PCT ≤ 1 ≤ 200 PCT
■ Initial setting value
l is a backed up value.
■ Default
l = 100 (mW)
9.48 LOFS [Level Offset]
■ Function
Sets a level offset value.
Inputting a level offset value will move the displayed spectrum the distance
equivalent to the level offset.
Header Program Query Response
LOFS LOFS n LOFS ? n
■ Value of n
n indicates a level offset value.
The unit is dB. Input a value down to the second decimal place.
Data range: –30.00 dB ≤ n ≤ + 30.00 dB
9.48 LOFS [Level Offset]
