Anritsu MS9710C - DBB [Memory Data B]; DCA [Data Condition Memory A]

9-31
9.21 DCA [Data Condition Memory A]
9.20 DBB [Memory Data B]
■ Function
Outputs binary measurement data equivalent to the number of sampling points
from memory B.
The count of data in memory B is equal to the number of sampling points.
Header Program Query Response
DBB None DBB ? d
(equivalent to the number of
sampling points; binary data)
■ Value of d
d indicates measurement data. The data format depends on the scale.
See Appendix B, “Binary Data Transfer Format.”
Note:
In the 3-dimensional or overlapping display mode, the last measurement
data is output.
In the normalize display mode, an absolute level is output.
9.21 DCA [Data Condition Memory A]
■ Function
Reads data measurement conditions from memory A.
Header Program Query Response
DCA None DCA ? λ 1, λ 2, n
■ • Value of λ 1
λ 1 indicates a start wavelength. The unit is always nm. A value is output down
to the second decimal place.
• Value of λ 2
λ 2 indicates a start wavelength. The unit is always nm. A value is output down
to the second decimal place.
• Value of n
n indicates a sampling point, 251, 501, 1001, 2001, or 5001.
