11-5
LabVIEW Measuring Instrument
11
11.3 List of Measuring Instrument Drivers
The measuring instrument driver file name is assigned as follows:
MS9710A
(card name);(function key name).vi
or
MS9710A (name corresponding to panel key or function).vi
(For he GPIB driver
, is left blank. For the RS-232C driver, is entered with S.)
Icons resemble the keys on the main unit.
You can select drivers according to the main unit key operation. In most case, you can select the drivers to be used
by imagining the main unit key operations.
Drivers for Front Card Functions
Wavelength Setting
Card name ;Function key name Function
Wavelength ;Center/Start/Stop Set a center wavelength, start wavelength, stop wavelength.
Wavelength ;Set Span Set a sweep span.
Wavelength ;Air/Vacuum Switch between wavelength display modes (in Air/in Vacuum).
Wavelength ;Mkr Value WL/Freq Switch between marker wavelength/frequency display modes.
Level Setting
Card name ;Function key name Function
LevelScale ;Log/Linear Set a log/linear scale.
LevelScale ;REF Level Set a reference level.
LevelScale ;Opt.Att Off/On Turn on/off the optical attenuator.
Resolution and Averaging Setting
Card name ;Function key name Function
Res/BW/Avg ;Res/BW/SmplPt Set resolution, light video bandwidth, or number of sampling
points.
Res/BW/Avg ;Actual Resolution Switches between actual resolution display modes.
Res/BW/Avg ;Average Set Point/Sweep Average or Smooth.
Peak and Dip Detection
Card name ;Function key name Function
Peak/Dip ;Peak/DipSearch(1) Detect a peak/dip whose level is highest.
Peak/Dip ;Peak/DipSearch(2) Detect a peak/dip whose level is the second lowest/highest or a
peak/dip whose wavelength is the second shortest/longest.
11.3 List of Measuring Instrument Drivers
