Section 11 LabVIEW Measuring Instrument
11-6
Waveform Analysis
Card name ;Function key name Function
Analysis ;Threshold Threshold
Analysis ;ndB-Loss ndB-Loss
Analysis ;SMSR Side mode suppression ratio
Analysis ;Envelope Envelop
Analysis ;RMS RMS
Analysis ;Spectrum Power Power integration
Analysis ;Analysis Off Analysis mode end
Memory and Trace Setting
Card name ;Function key name Function
Trace ;Set Memory/Trace Switches between memories A and B or select a trace mode
among A, B, A & B, A-B, and B-A.
Measurement data save/recall
Card name ;Function key name Function
Save/Recall ;FD Save, recall, delete data or format a FD.
Drivers for Back Card Function
Graph Display Method Switching
Card name ;Function key name Function
Graph ;Graph Clear Clear a graph
Graph ;Set Display Mode Switch between normal, overlap, max. hold, normalize, and
3-dimensional display modes.
Applicable measurement functions
Card name ;Function key name Function
Appli ;DFB-LD Test Evaluate DFB-LD.
Appli ;FP-LD Test Evaluate FP-LD.
Appli ;LED Test Evaluate LED.
Appli ;PMD Test Evaluate PMD.
Appli ;Multi Peak Detect multiple peaks. (WDM Analysis)
Appli ;Opt.Amp Mode Evaluate the optical amplifier.
Appli ;Opt.Amp Result Evaluate the optical amplifier (output the measurement result).
Appli ;Opt.Amp-Parameter Evaluate the optical amplifier (set parameters).
Appli ;Opt.Amp-Pin/Pout Evaluate the optical amplifier (switches between signal light types
(Pin/Pout).
Appli ;Opt.Amp-Pout to ase Evaluate the optical amplifier (copy Pout data to the Pase
memory)
Appli ;Opt.Amp-Res.Cal Evaluate the optical amplifier (calibrate resolution).
Continued
