Anritsu MS9710C - MKC [Level Marker C]

Section 9 Details on Device Messages
9-48
9.54 MKC [Level Marker C]
■ Function
Sets level marker C with a level.
Header Program Query Response
MKC MKC l MKC ? l
■ Value of l
λ is a level value including the unit of the trace marker on the set scale.
When the log scale is selected, λ is a value represented down to the third decimal
place. When the linear scale is selected, it is represented by a maximum of seven
digits.
Data range:
–190DBM ≤ l ≤ +50 DBM .....Log scale, normal/max. hold/overlap, trace A/B/AB
–160DB ≤ l ≤ +160 DB .......Log scale, normal/max. hold/overlap, trace A-B/
B-A
Log scale, normalize
–200DB ≤ l ≤+120 DB........Linear scale, normal/max. hold/overlap, trace A/
B/AB
0PW ≤ l ≤ 1.2 W............Linear scale, normal/max. hold/overlap, trace A/
B/AB
0PCT ≤ l ≤ 240 PCT .......Linear scale, normal/max. hold/overlap, trace A-
B/B-A
Linear scale, normalize
■ Suffixes
DBM: Log scale, normal/max. hold/overlap, trace A/B/AB
DB: Log scale, normal/max. hold/overlap, trace A-B/B-A
Log scale, normalize
W: Linear scale, normal/max. hold/overlap, trace A/B/AB
MW: Linear scale, normal/max. hold/overlap, trace A/B/AB
UW: Linear scale, normal/max. hold/overlap, trace A/B/AB
NW: Linear scale, normal/max. hold/overlap, trace A/B/AB
PW: Linear scale, normal/max. hold/overlap, trace A/B/AB
PCT: Linear scale, normal/max. hold/overlap, trace A-B/B-A
Linear scale, normalize
