3.1 GPIB Standard
The standard for the GPIB of the MS9710C is summarized below.
Item Standard value and description
Function
Interface
functions
Conforms to IEEE 488.2.
MS9710C can be controlled from an external controller.
MS9710C can control a printer.
SH1: All of source handshake functions are supported.
Data send timing is controlled.
AH1: All of acceptor handshake functions are supported.
Data receive timing is controlled.
T6: Basic talker functions are supported. A serial port function
is supported.
A talk-only function is not supported. The function of
releasing the talker with MLA is supported.
L4: Basic listener functions are supported. A listen-only func-
tion is not supported. The function of releasing the listener
by MTA is supported.
SR1: All of service request/status byte functions are supported.
RL1: All of remote/local functions are supported.
A local lockout function is supported.
PP0: A parallel poll function is not supported.
DC1: All of device clear functions are supported.
DT0: A disk trigger function is not supported.
C0: A controller function is not supported.
A controller function is performed during external plot output.
3.2 RS-232C Standard
The standard for the RS-232C of the MS9710C is summarized below.
Item Standard value
Function
Communication method
Communication control method
Baud rate
Data bits
Parity
Start bits
Stop bits
Connector
Control from external controller
Asynchronous (start-stop), half-duplex
No flow control
600, 1200, 2400, 4800, 9600 bps
7 bits, 8 bits
Odd parity (ODD), even parity (EVEN),
non-parity (NON)
1 bit
1 bit, 2 bits
D-sub 9-pin connector, female
