Anritsu MS9710C User Manual

9-33
9.24 DMA [Memory Data A]
■ Function
Outputs ASCII measurement data equivalent to the number of sampling points
from memory A.
The count of data in memory A is equal to the number of sampling points.
Header Program Query Response
DMA None DMA ? d + Terminator
(equivalent to the number of
sampling points)
■ Value of d
d indicates measurement data. The data format depends on the scale.
The response data does not have a header, and x’s are zero-suppressed.
Log scale .......... d =± xxx.xx (Unit: dBm)
(–120 dBm ≤ d ≤ +30 dBm)
Linear scale ...... d = xx.xxxxE ± xx (Unit: mW)
(0.1000 < Mantissa part ≤ 1.0000, –8 ≤ Exponent ≤ +3)
Note:
In the 3-dimensional or overlapping display mode, the last measurement
data is output.
In the normalize display mode, an absolute level is output.
9.24 DMA [Memory Data A]
