Section 11 LabVIEW Measuring Instrument
11-10
11.4.2 Description of functions
For input parameter setting ranges, output data formats, and so forth, see the help window.
( ) following an input parameter indicates an initial value (default).
The file name of the RS-232C is “MS9710AS...”.
MS9710A Close
MS9710
close
This driver terminates communication with the device.
Execute it at the end of the program.
This driver is not included in the RS-232C library.
MS9710A Error Message
MS9710
ErrMsg
MS9710A Error Message Japanese
Executing this VI after executing a measuring instrument driver will display an error location, error code, and error
message if any error has occurred.
If the error is an MS9710C-specific error, the value “MS9710C error code + 5000” is output.
For details on MS9710C error codes, see Appendix A.
(“101 Can’t Find Peak” and “102 Can’t Find Dip” are not handled as errors.)
“MS9710A Error Message Japanese” displays error messages in Japanese.
Input parameter:
type of dialog (OK msg:1).......... Select an error message display dialog type.
Output parameters:
status ........................................... Indic puts an error message.
code ............................................ Error code
error message .............................. Error location
To Next Page
