Anritsu MS9710C - LOG [Log Scale]; LVS [Level Scale]; MDM [Modulation Mode]

Section 9 Details on Device Messages
9-46
9.49 LOG [Log Scale]
■ Function
Selects a log scale as a level sale and sets a scale value (dB/div).
Header Program Query Response
LOG LOG l LOG ? l
■ Value of l
The unit is dB/div. Input a value down to the first decimal place.
Data range:0.1 ≤ l ≤ 10.0
■ Initial setting value
l is a backed up value.
■ Default
l = 10 (dB/div)
9.50 LVS [Level Scale]
■ Function
Checks whether a log or linear scale is set as a level scale.
Header Program Query Response
LVS None LVS ? s
■ Value of s
s indicates a level sale type.
Log scale ................ LOG
Linear scale ............ LIN
9.51 MDM [Modulation Mode]
■ Function
Sets a modulation measurement mode.
Header Program Query Response
MDM MDM s MDM ? s
