Anritsu MS9710C User Manual

9-5
Details on Device Messages
9
ANA SMSR [Spectrum Analysis (SMSR)]
■ Function
Carries out an SMSR analysis.
When the processing is complete, bit 0 (measurement end bit) of the extended
event status register (ESR2) is set to 1.
Header Program Query Response
ANA ANA SMSR, s ANA ? SMSR, s
■ Value of s
s = 2NDPEAK: Carry out an analysis with respect to the side mode at second
highest level.
= LEFT: Carry out an analysis with respect to the side mode on the left
(shorter wavelength side) of the peak wave.
= RIGHT: Carry out an analysis with respect to the side mode on the right
(shorter wavelength side) of the peak wave.
■ Initial setting value
s is a backed up value.
■ Default
s = 2NDPEAK
ANA PWR [Spectrum Analysis (Spectrum Power)]
■ Function
Carries out power integration.
When the processing is complete, bit 0 (measurement end bit) of the extended
event status register (ESR2) is set to 1.
Header Program Query Response
ANA ANA PWR ANA ? PWR
ANA OFF [Spectrum Analysis Off]
■ Function
Turns off the analysis mode.
Header Program Query Response
ANA ANA OFF ANA ? OFF
9.2 ANA [Analysis] ANA ENV [Spectrum Analysis (Envelope)]
