Section 9 Details on Device Messages
9-8
AP FP [Application (FP - LD)]
■ Function
Measures FP-LD.
When the processing is complete, bit 0 (measurement end bit) of the extended
event status register (ESR2) is set to 1.
Header Program Query Response
AP AP FP, n AP ? FP, n
■ Value of n
n is the axis mode cut level (difference between the peak level and the cut level)
used for measuring the number of axis modes. The unit is dB. Input an integer.
Data range: 1 ≤ n ≤ 50
■ Initial setting value
n is a backed up value.
■ Default
n = 20 (dB)
AP LED [Application (LED)]
■ Function
Measures LED.
When the processing is complete, bit 0 (measurement end bit) of the extended
event status register (ESR2) is set to 1.
Header Program Query Response
AP AP LED, n , p AP ? LED, n , p
■ • Value of n
n is the value used for ndB-width measurement (ndB-down wave width). The
unit is dB. Input an integer.
Data range: 1 ≤ n ≤ 50
• Value of p
p is a total power compensation value. The unit is dB. Input a value is input down
to the second decimal place.
Data range: –10.00 ≤ n ≤ + 10.00
■ Initial setting value
n and p are backed up values.
■ Default
n = 3 (dB)
p = 0 (dB)
