Section 9 Details on Device Messages
9-22
APR? WDM [Application Result (WDM)]
■ Function
Queries WDM Application analysis results
Header Program Query Response
APR None
None
None
None
None
None
None
APR?
(analysis result link obtained)
APR? MPKC
APR? WDM, MPK, m
APR? WDM, SNR, m
APR? WDM, SNR, GAV
APR? WDM, REL, m
APR? WDM, TBL, m
n, λ1, L1, λ2, L2...
n, λ1, L1, S1, d1, l2, L2, S2, d2...
n, Rn, λ1, SP1, Rλ 1, L1, RL1, λ2,
SP2, Rλ2, L2, RL2...
n, λ1, f1, L1, S1, d1, SP1, SPf1, λ2, f2,
L2, S2, d2, SP2, SPf2...
MPKC, n
WDM, MPK, λ, L
WDM, SNR, λ, L, S, d
t
WDM, REL, λ, SP, Rλ, L, RL
WDM, TBL, λ, f, L, S, d, SP, SPf
■ Send Data
• Value of m
m indicates the query peak number.
m = 1 to 300
■ Response
• Value of n
n is the peak number.
n = 0 to 300
• Value of λk (λ1, λ2, λ3,...)
λk indicates the wavelength of peak No. k.
λk = xxxx.xx in nm units to two decimal places
• Value of fk (f1, f2, f3,...)
fk indicates the value of the frequency of peak No. k.
f = xxx.xxxx: Outputs values in fixed THz units to four decimal places.
• Value of Lk (L1, L2, L3,...)
Lk indicates the level of peak No. k.
Lk = xxxx.xx in dBm unit to two decimal places.
