10-7
The array data DT ( ) represented in ASCN numeric format is the same as the array data D ( ) which is the
numeric data converted from binary data.
When the log scale is selected, 1-point measurement data is represented by two bytes. When the linear scale is
selected, 1-point measurement data is represented by four bytes. For the binary data format, see Appendix B. The
time needed to read the whole data on 501 points varies with the data value as follows:
DMA? DQA?
Read Conversion
Read +
Conversion
DBA?
Log data
Linear data
7.5 to 8.0
8.0 to 8.5
1.7
2.0
0.5
0.9
0.7
2.3
1.2
3.2
Unit: Second
10.2 Program Examples
