Section 11 LabVIEW Measuring Instrument
11-18
MS9710A Appli ;Multi Peak
MS9710
MultiPk
This driver detects multiple peaks and outputs the detected peak wavelengths and levels.
This icon is to keep compatibility with the older version. Normally use the WDM and WDM-R.
Input parameter:
S.Level (dB) (no change) ........... Set a slice level (1 to 50 dB).
When no value is input, the previous setting is used.
Output parameters:
Peak Count ................................. Outputs the number of detected peaks.
Wavelength (nm) ........................ Outputs detected peak wavelengths as arrays in ascending order of wavelength.
Level (dBm) ............................... Outputs detected peak levels as arrays in ascending order of wavelength.
MS9710A Appli ;Opt.Amp Mode
MS9710
Amp
This driver selects the optical AMP measurement mode.
MS9710A Appli ;Opt.Amp Result
MS9710
Amp-R
This driver outputs the optical AMP measurement result.
Output parameters:
Result [cluster] ........................... Outputs the following cluster elements:
1. Gain (dB) .............................. Optical amplifier gain (amplification ratio)
(If analysis is impossible, –999.99 is output.)
2. NF (dB) ................................ Optical amplifier NF (If analysis is impossible, –999.99 is output.)
3. Signal Wevelength (nm) ...... Signal light peak wavelength (If analysis is impossible, –1 is output.)
4. ASE Level (/Res) (dBm) ...... ASE level per resolution (If analysis is impossible, –999.99 is output.)
5. Res (nm) ............................... Resolution data used for NF measurement
