3.3 Device Message List
MS9710C Device Message List (6/13)
Function
Command
Data
request
Response
AP AMP, PRM,
a, b, c, d, e,
f, g, h, i, j, k
AP AMP, ASE
AP OFF
AP WDM
AP WDM, SLV, s
s = 1 to 50
AP WDM, MPK
AP WDM,
SNR, d, ∆ λ
, S
d = "HIGHER",
"LEFT",
"RIGHT"
= AVERAGE
∆ λ = 0.01 to
20.00, "OFF"
s=ON
= OFF
AP WDM, REL, r
r = 1 to 50
OFF
AP WDM,m
m= "MPK",
"SNR",
"REL"
AP WDM, SLV, s
s = 1 to 50
(AP, WDM,
MPK)
AP WDM,
SNR, d, ∆ λ
d = "HIGHER",
"LEFT",
"RIGHT"
= AVERAGE
∆ λ = 0.01 to
20.00, "OFF"
s=ON
OFF
AP WDM, REL, r
r = 1 to 50
AP?
AMP,
PRM
AP?
AP?
AP? WDM,
SLV
AP? WDM,
MPK
AP? WDM,
SNR
AP? WDM,
REL
AMP, PRM,
a, b, c, d, e,
f, g, h, i, j, k
a : NF Calculation
b : NF Measurement method
c : Fitting Method
d : Fitting Span : 0.10 to 100.00 nm
e : Masked Span : 0.10 to 100.00 nm
f : Pin Loss : –10.00 to 10.00 dB
g : Pout Loss : –10.00 to 10.00 dB
h : NF Cal : 0.100 to 10.000
i : O.BPF Level CaL : 0.00 to 30.00 dB
j : O.BPF BW : 0.01 to 999.99 nm
k : Pol Loss : –10.00 to 10.00 dB
Device message
Remarks
Applica
-tion
O.Amp
Parameter
Pout→Pase
Off
WDM
WDM
S. Level
WDM
Multi Peak
WDM SNR
WDM
Relative
Display Mode is previ-
ous condition, MPK,
SNR, REL mean Multi
Peak, SNR, and Relative
displays, respectively.
S is splice level.
In this case only, same
result at AP?
d is the Dip detection direc-
tion, ∆ λ is the detection
position in 0.01 nm steps;
at ∆ λ = OFF or 0, detects
dip in direction set at d.
s is ON/OFF of normaliz-
ing noise with the effec-
tive resolution.
r is the reference peak
number
9.4
a = 0 : S-ASE, 1 : Total
b = 0 : SpectDiv Off, 1 : On
2 : PlznNull Method
3 : Pulse Method
4 : WDM Measure
c = 0 : Gauss, 1 : Mean
d : Fit Span
e : Mask Span
f : Pin Loss
g : Pout Loss
h : NF Cal
i : O.BPF LCal
j : O.BPF BW
k : Pol Loss
