Assembly Removal and Replacement, MS202xC 6-26 Replacing Fan Assembly – ND70948
MS20xxC MM PN: 10580-00307 Rev. D 6-63
1. Cable, Ext Trig Input, to MB J3202
2. Cable, Ext Ref Input, to MB J2200
3. Cable, VNA Reference, 26 MHz, to MB J2201
4. Location of Power Monitor Connector (Option 5) or hole plug (Power Monitor option not installed)
5. External Trigger Input Connector
6. External Reference Input Connector
7. Location of GPS Antenna Connector (Option 31) or hole plug
Figure 6-24. Cables Connecting Main PCB (Mother Board) and VNA PCB (MS2028C shown)
