Anritsu VNA Master MS2026C Maintenance Manual

General Information 1-8 Replaceable Parts and Assemblies
MS20xxC MM PN: 10580-00307 Rev. D 1-9
ND75365
Main PCB Assembly for MS2037C instruments
– VNA Module not included
– SPA Assembly not included
– LCD Display not included
– Section 7-21 “Removing MS203xC Main PCB Assembly” on page 7-54
– Section 7-22 “Replacing MS203xC Main PCB Assembly” on page 7-61
ND72087
Main PCB Assembly for MS2038C instruments for s/n <1148151
– VNA Module not included
– SPA Assembly not included
– LCD Display not included
– Section 7-21 “Removing MS203xC Main PCB Assembly” on page 7-54
– Section 7-22 “Replacing MS203xC Main PCB Assembly” on page 7-61
ND74893
Main PCB Assembly for MS2038C instruments for s/n >=1148151
– VNA Module not included
– SPA Assembly not included
– LCD Display not included
– Section 7-21 “Removing MS203xC Main PCB Assembly” on page 7-54
– Section 7-22 “Replacing MS203xC Main PCB Assembly” on page 7-61
ND72088
VNA Module Assembly with N(f) connectors for MS2026C Instruments
– Section 6-18 “Replacing VNA PCB Assembly” on page 6-30
ND72089
VNA Module Assembly with N(f) connectors for MS2027C and MS2028C Instruments
– For MS2027C and MS2028C instruments equipped with standard N(f) Test Ports
– Section 6-18 “Replacing VNA PCB Assembly” on page 6-30
ND72090
VNA Module Assembly with K(f) connectors for MS2028C Instruments
– For MS2028C instruments equipped with Option 11 K(f) Test Ports
– Section 6-18 “Replacing VNA PCB Assembly” on page 6-30
ND72091
VNA Module Assembly with N(f) connectors for MS2036C Instruments
– Section 7-18 “Replacing VNA PCB Assembly” on page 7-37
ND72092
VNA Module Assembly with N(f) connectors for MS2037C and MS2038C Instruments
– For MS2037C and MS2038C instruments equipped with standard N(f) Test Ports
– Section 7-18 “Replacing VNA PCB Assembly” on page 7-37
ND72093
VNA Module Assembly with K(f) connectors for MS2038C Instruments
– For MS2038C instruments equipped with Option 11 K(f) Test Ports
– Section 7-18 “Replacing VNA PCB Assembly” on page 7-37
ND72094
SPA Assembly with N(f) connector for MS2036C Instruments
– Section 7-17 “Replacing SPA Module Assembly” on page 7-31
ND72095
SPA Assembly with N(f) connector for MS2037C and MS2038C Instruments
– For MS2037C and MS2038C instruments equipped with standard N(f) Test Ports
– Section 7-17 “Replacing SPA Module Assembly” on page 7-31
MD72096
SPA Assembly with K(f) connector for MS2038C Instruments
– For MS2038C instruments equipped with Option 11 K(f) Test Ports
– Section 7-17 “Replacing SPA Module Assembly” on page 7-31
ND67197
Power Monitor PCB Assembly, Option 5
– For MS2026C, MS2027C and MS2028C instruments equipped with Option 5 Power Monitor
– Section 6-17 “Replacing Power Monitor PCB Assembly, Option 5 – ND67197” on page 6-27
Table 1-7. Replaceable Parts and Assemblies (2 of 5)
Part Number Description
