Anritsu VNA Master MS2026C Maintenance Manual

1-8 Replaceable Parts and Assemblies General Information
1-10 PN: 10580-00307 Rev. D MS20xxC MM
ND70320
GPS Receiver Module, Option 31
– Does not include GPS Antenna 2000-1528-R
– For MS2026C, MS2027C and MS2028C instruments equipped with Option 31 GPS Receiver
– Section 6-19 “Replacing GPS Receiver Module (Option 31) – ND70320” on page 6-37
– For MS2036C, MS2037C and MS2038C instruments equipped with Option 31 GPS Receiver
– Section 7-19 “Replacing GPS Receiver Module (Option 31) – ND70320” on page 7-45
3-15-154
LCD Display
– For all MS202xC and MS203xC instruments
– Section 6-23 “Replacing LCD Display – 3-15-154” on page 6-50
– Section 7-23 “Replacing LCD Display – 3-15-154” on page 7-64
3-61368
Clear Plastic LCD Protector
– For all MS202xC and MS203xC instruments
– Section 6-24 “Replacing Clear Plastic LCD Protector – 3-61368” on page 6-51
– Section 7-24 “Replacing Clear Plastic LCD Protector – 3-61368” on page 7-66
3-61362
Main Keypad Rubber Membrane
– For all MS202xC and MS203xC instruments
– Section 6-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 6-12
– Section 7-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 7-13
3-71027-3
Main Keypad PCB
– For all MS202xC and MS203xC instruments
– Section 6-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 6-12
– Section 7-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 7-13
3-61363-1
Main Keypad Plastic Bezel
– For all MS202xC and MS203xC instruments
– Section 6-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 6-12
– Section 7-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 7-13
3-61361
Main Menu Keypad Rubber Membrane
– For all MS202xC and MS203xC instruments
– Section 6-12 “Replacing Main Menu Keypad Rubber Membrane – 3-61361” on page 6-15
– Section 7-13 “Replacing Main Menu Keypad Components” on page 7-19
3-71030-3
Main Menu Keypad Flex PCB
– For all MS202xC and MS203xC instruments
– Section 6-13 “Replacing Main Menu Keypad Components” on page 6-17
– Section 7-13 “Replacing Main Menu Keypad Components” on page 7-19
3-61378-1
Main Menu Keypad Plastic Bezel
– For all MS202xC and MS203xC instruments
– Section 6-13 “Replacing Main Menu Keypad Components” on page 6-17
– Section 7-13 “Replacing Main Menu Keypad Components” on page 7-19
3-410-101
Rotary Encoder
– For all MS202xC and MS203xC instruments
– Does not include the Rotary Knob 3-61360-2
– Section 6-20 “Replacing Rotary Encoder – 3-410-101” on page 6-41
– Section 7-20 “Replacing Rotary Encoder – 3-410-101” on page 7-49
3-61360-2
Encoder Rotary Knob (excluding encoder)
– For all MS202xC and MS203xC instruments
– Does not include the Rotary Encoder 3-410-101
– Section 6-15 “Replacing Rotary Knob – 3-61360-2” on page 6-23
– Section 7-15 “Replacing Rotary Knob – 3-61360-2” on page 7-25
Table 1-7. Replaceable Parts and Assemblies (3 of 5)
Part Number Description
