Anritsu VNA Master MS2026C Maintenance Manual

General Information 1-8 Replaceable Parts and Assemblies
MS20xxC MM PN: 10580-00307 Rev. D 1-11
ND70948
Fan Assembly
– For all MS202xC and MS203xC instruments
– Section 6-26 “Replacing Fan Assembly – ND70948” on page 6-57
– Section 7-26 “Replacing Fan Assembly – ND70948” on page 7-77
790-625
Speaker
– For all MS202xC and MS203xC instruments
The replacement procedure is not described separately. The speaker is attached to the Main
Keypad PCB. Refer to:
– Section 6-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 6-12
– Section 7-11 “Replacing Main Keypad Components – 3-61362, 3-71027-3” on page 7-13
3-61470
Hand Strap
– For all MS202xC and MS203xC instruments
– Section 6-14 “Replacing Hand Strap – 3-61470” on page 6-22
– Section 7-14 “Replacing Hand Strap – 3-61470” on page 7-24
3-61571
Hand Strap Ring Holder
– For all MS202xC and MS203xC instruments
– Two each per instrument
– The replacement procedure is not described separately. Refer to:
– Section 6-14 “Replacing Hand Strap – 3-61470” on page 6-22
– Section 7-14 “Replacing Hand Strap – 3-61470” on page 7-24
3-905-2685
Hand Strap Ring Holder Mounting Screw
– For all MS202xC and MS203xC instruments
– Two each per instrument
– The replacement procedure is not described separately. Refer to:
– Section 6-14 “Replacing Hand Strap – 3-61470” on page 6-22
– Section 7-14 “Replacing Hand Strap – 3-61470” on page 7-24
3-68100-2
Top Case
– For all MS202xC and MS203xC instruments
– Does not include Model ID Label and keypad items
ND68809
Bottom Case with Tilt Bail
– For all MS202xC instruments
ND71717
Bottom Case with Tilt Bail
– For all MS203xC instruments
3-68110 Model ID Label for MS2026C instruments
3-74316 Model ID Label for MS2027C instruments
3-68111 Model ID Label for MS2028C instruments
3-68168 Model ID Label for MS2036C instruments
3-74317 Model ID Label for MS2037C instruments
3-68182 Model ID Label for MS2038C instruments
61379-2
Battery Door
– For all MS202xC instruments
– Refer to Chapter 5 for replacement of the battery door
3-67151-2
Battery Door
– For all MS203xC instruments
– Refer to Chapter 5 for replacement of the battery door
Table 1-7. Replaceable Parts and Assemblies (4 of 5)
Part Number Description
