Spectrum Analyzer Performance Verification 3-9 Amplitude Accuracy
MS20xxC MM PN: 10580-00307 Rev. D 3-23
2. Set the frequency of the MG3692X to 50 MHz CW.
Figure 3-3. Amplitude Accuracy Verification Test Setup - Characterization
Caution
In order to maintain test setup integrity, do not disconnect Sensor B, the Power Splitter, or the Fixed
Attenuator.
Note Before continuing, allow a 30-minute warm up for the internal circuitry to stabilize.
Attenuator
Adapter
Adaptor
10 MHz Reference
MG369XA Source
ML2438A Power Meter
Sensor B
Power Splitter
Sensor A
To Next Page
