Service Manual i2000SR interface module
625798100.APS.5.doc Page 113 of 212
VERIFICATION
STEPS REFERENCES
1 With the i2000SR IM in the APS
position, restore power to the
workcell.
1. Turn i2000SR IM power switch
to APS position
2. Power on the Accelerator APS
UPS
No. Description
1 Bar Code Scanner beeps
once then twice.
2 Pole Instrument Indicator
Light turns RED
3 Tag Reader LEDs turn on
4 Pole RED lamp blinks until
the Master Slave to i2000SR
SCC communication check is
passed
1. SCC CLI Edgeport
port 1 (com 3)
2. Master Slave Port 2
(CLI)
3. SCC LAS Edgeport
port 4 (com 6)
4. Master Slave Port 1
(LAS)
NOTE:
The i2000SR IM will not initialize
unless the cable check is passed.
Refer to the “Accelerator APS Operations Manual –
SECTION 5 – Operating Instructions” to execute
the “Restoring Power after a Controlled Shutdown”
of the Workcell.
2 Press the START button. Wait until
the IM carriers are in initialized
location.
3 At the i2000SR IM LUI keypad,
activate IM exercise by pressing and
holding the START key while the
PAUSE button is pressed.
Verify that the YELLOW lamp comes
ON.
4 Allow the carriers to complete one
cycle.
5 At the i2000SR, use the SCC to place
the i2000SR in RUN.
Verify that after the i2000SR is in
RUN, the GREEN lamp is ON.
6 Turn the i2000SR IM switch to the O
position.
7 Turn the i2000SR IM switch to the
APS position.
To Next Page
