i2000SR interface module Service Manual
Page 98 of 212 625798100.APS.5.doc
STEPS REFERENCES
32 Install the center cover by tightening
the four (4) ¼ turn screws.
33 Install the screw in the Center Rail [2]
Install the Hinge Mount (P/N 203621)
and two front covers by installing the
four (4) countersink screws [1].
To Next Page
