Room Devices
Telligence
58PM000224A / 10 August 2022 / Ver. H
(5) Flashlight Control: Activates and deactivates the built-in flashlight.
(6) Sun Blind Control: Raises and lowers the sun blinds in patient rooms equipped with a Sun
Blind Control module.
(7) TV Channel Up/Down: Changes television channels.
(8) TV Control: Adjusts entertainment audio, only. The buttons do not control nurse call
intercom. The intercom between the patient and the nurse station can only be adjusted at the
staff console, annunciator, or TelliConnect station.
(9) TV/Radio On/Off: Turn the television and radio on and off.
Figure 60: 1, 3, and 7 Button Handsets
Pillow Speaker Controls
Pillow speaker buttons and capabilities differ slightly from those on a handset.
Figure 61: Pillow Speaker 1 With Sun Blind Control
Legend:
(1) Speaker and Microphone: Provides two-way communications.
(2) Nurse Call: Places a nurse call request.
1-button
3-button 7-button
(2)
(1)
(7)
(9)
(8)
(3)
(5)
(4)
(6)
