Audi Q7 2007 !
6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
Repair Group 10 – Removing and installing engine
6
8
– Detach coolant hose -1-.
– Disconnect vacuum hose going to vacuum reservoir -2-.
– Lay a clean cloth under the separating points to catch es-
caping fuel.
– Detach fuel supply hose -6- from fuel filter.
– Detach fuel hose going to fuel cooler at the connections
marked -3- and -5-.
– Remove bolts -1- and -2- and nut -4-.
– Move fuel lines at bulkhead clear and lay aside fuel filter
with fuel hoses connected.
– Remove bolts -1 ... 4-.
The fuel filter bracket remains installed.
– Open cover above terminal B+ -arrow-.
– Unscrew positive cable -1- going to starter and alternator
and move electrical wiring clear.
Caution!
Observe rules for cleanliness when working on the injection
system ⇒ page 2.
Note
