AudioCodes MediaPack Series MP-11x

Version 6.6 395 MP-11x & MP-124
User's Manual 40. Testing SIP Signaling Calls
Parameter Description
Route By
[Test_Call_DestType]
Defines the type of routing method. This applies to incoming and
outgoing calls.
 [0] GW Tel2IP = (Default) Calls are matched by (or routed to)
an SRD and Application type (defined in the SRD and
Application Type parameters below).
 [1] IP Group = Calls are matched by (or routed to) an IP Group
ID.
 [2]
Dest Address = Calls are matched by (or routed to) an SRD
and application type.
Notes:
 For REGISTER messages, the option [0] cannot be used as
the routing method.
 For REGISTER messages, if option [1] is used, only Server-
type IP Groups can be used.
IP Group ID
[Test_Call_IPGroupID]
Defines the IP Group ID to which the test call is sent or from
which it is received.
Notes:
 This parameter is applicable only if option [1] is configured for
the 'Route By' parameter.
 This IP Group is used for incoming and outgoing calls.
Destination Address
[Test_Call_DestAddress]
Defines the destination host. This can be defined as an IP
address[:port] or DNS name[:port].
Note: This parameter is applicable only if the 'Route By'
parameter is set to [2] (Dest Address).
Destination Transport Type
[Test_Call_DestTransportType]
Defines the transport type for outgoing calls.
 [-1] Not configured (default)
 [0] UDP
 [1] TCP
 [2] TLS
Note: This parameter is applicable only if the 'Route By'
parameter is set to [2] (Dest Address).
Authentication Tab
Auto Register
[Test_Call_AutoRegister]
Enables automatic registration of the endpoint. The endpoint can
register to the device itself or to the 'Destination Address' or 'IP
Group ID' parameter settings (see above).
 [0] False (default)
 [1] True
User Name
[Test_Call_UserName]
Defines the authentication username.
By default, no username is defined.
Password
[Test_Call_Password]
Defines the authentication password.
By default, no password is defined.
Test Settings Tab
