AudioCodes MediaPack Series MP-11x User Manual

User's Manual 522 Document #: LTRT-65417
MP-11x & MP-124
Parameter Description
Mode
[Tel2IPCallForkingMode]
multiple IP destinations.
 [0] Disable (default)
 [1] Enable
Note: Once enabled, routing rules must be assigned Forking Groups in
the Outbound IP Routing table.
Web/EMS: Enable Reason
Header
[EnableReasonHeader]
Enables the usage of the SIP Reason header.
 [0] Disable
 [1] Enable (default)
Web/EMS: Gateway Name
[SIPGatewayName]
Defines a name for the device (e.g., device123.com').
Notes:
 Ensure that the name defined is the one with which the Proxy is
configured to identify the device.
 If specified, the device name is used as the host part of the SIP URI
in the From header. If not specified, the device's IP address is used
instead (default).
[ZeroSDPHandling]
Determines the device's response to an incoming SDP that includes an
IP address of 0.0.0.0 in the SDP's Connection Information field (i.e.,
"c=IN IP4 0.0.0.0").
 [0] = (Default) Sets the IP address of the outgoing SDP's c= field to
0.0.0.0.
 [1] = Sets the IP address of the outgoing SDP c= field to the IP
address of the device. If the incoming SDP doesn’t contain the
"a=inactive" line, the returned SDP contains the "a=recvonly" line.
Web/EMS: Enable Delayed
Offer
[EnableDelayedOffer]
Determines whether the device sends the initial
INVITE message with or
without an SDP. Sending the first INVITE without SDP is typically done
by clients for obtaining the far-end's full list of capabilities before
sending their own offer. (An alternative method for obtaining the list of
supported capabilities is by using SIP OPTIONS, which is not supported
by every SIP agent.)
 [0] Disable = (Default) The device sends the initial INVITE message
with an SDP.
 [1]
Enable = The device sends the initial INVITE message without an
SDP.
[DisableCryptoLifeTimeIn
SDP]
Enables the device to send "a=crypto" lines without the lifetime
parameter in the SDP. For example, if the SDP contains "a=crypto:12
AES_CM_128_HMAC_SHA1_80
inline:hhQe10yZRcRcpIFPkH5xYY9R1de37ogh9G1MpvNp|2^31", it
removes the lifetime parameter "2^31".
 [0] Disable (default)
 [1] Enable
Web/EMS: Enable Contact
Restriction
[EnableContactRestrictio
n]
Determines whether the device sets the Contact header of outgoing
INVITE requests to ‘anonymous’ for restricted calls.
 [0] Disable (default)
 [1] Enable
[AnonymousMode]
Determines whether the device's IP address is used as the URI host
part instead of "anonymous.invalid" in the INVITE's From header for Tel-
to-IP calls.
 [0] = (Default) If the device receives a call from the Tel with blocked
caller ID, it sends an INVITE with
From: “anonymous”<anonymous@anonymous.invalid>
