PREFIX 0 = *, domain.com, *, 0, 255, $$, -1, , 1, , -1, -1, -1,,;
PREFIX 1 = 20, 10.33.37.77, *, 0, 255, $$, -1, , 2, , 0, -1,,;
Note: For a detailed description of this table, see
'Configuring Tel to IP Routing' on page 223.
IP to Hunt Group Routing Table
Web: IP to Hunt Group Routing Table
EMS: SIP Routing > IP to Hunt
[PSTNPrefix]
This table parameter configures the routing of IP-to-Hunt
Groups. The format of this parameter is as follows:
[PSTNPrefix]
ORMAT PstnPrefix_Index = PstnPrefix_DestPrefix,
PstnPrefix_TrunkGroupId, PstnPrefix_SourcePrefix,
PstnPrefix_SourceAddress, PstnPrefix_ProfileId,
PstnPrefix_SrcIPGroupID, PstnPrefix_DestHostPrefix,
PstnPrefix_SrcHostPrefix, PstnPrefix_SrcSRDID,
PstnPrefix_TrunkId;
[\PSTNPrefix]
For example:
PstnPrefix 0 = 100, 1, 200, *, 0, 2, , , ,;
PstnPrefix 1 = *, 2, *, , 1, 3, acl, joe, , ,;
Note: For a detailed description of this table, see
'Configuring IP to Hunt Group Routing Table' on page 230.
Web/EMS: IP to Tel Routing Mode
[RouteModeIP2Tel]
Determines whether to route IP calls to the Hunt Group
before or after manipulation of the destination number
(configured in 'Configuring Source/Destination Number
Manipulation Rules' on page 209).
 [0] Route calls before manipulation = (Default) Calls are
routed before the number manipulation rules are applied.
 [1] Route calls after manipulation = Calls are routed after
the number manipulation rules are applied.
Web: IP Security
EMS: Secure Call From IP
[SecureCallsFromIP]
Determines the device's policy on accepting or blocking SIP
calls (IP-to-Tel calls). This is useful in preventing unwanted
SIP calls, SIP messages, and/or VoIP spam.
 [0] Disable = (Default) The device accepts all SIP calls.
 [1] Secure Incoming calls = The device accepts SIP calls
(i.e., calls from the IP side) only from IP addresses that
are defined in the Tel to IP Routing or Proxy Set table, or
IP addresses resolved from DNS servers from FQDN
values defined in the Proxy Set table. All other incoming
calls are rejected.
 [2] Secure All calls = The device accepts SIP calls only
from IP addresses (in dotted-decimal notation format)
that are defined in the Tel to IP Routing table or Proxy
Set table, and rejects all other incoming calls. In addition,
if an FQDN is defined in the routing table or Proxy Set
table, the call is allowed to be sent only if the resolved
DNS IP address appears in one of these tables;
otherwise, the call is rejected. Therefore, the difference
between this option and option [1] is that this option is
concerned only about numerical IP addresses that are
defined in the tables.
Note: If this parameter is set to [1] or [2], when using
Proxies or Proxy Sets, it is unnecessary to configure the
