AVALEX TECHNOLOGIES AVR8414 User Manual

Page | 93 of 105
AVR8414 Operation Manual – Rev O
Dimming
OLED Control
Selects the signal which controls the
dimming level of the front panel
OLED screen.
Plus-minus-
buttons, photo-
cell, potentiometer
Plus-minus-
buttons
Bezel Control
Selects the signal which controls the
dimming level of the front panel
button backlights.
Plus-minus-
buttons, photo-
cell, potentiometer
Plus-minus-
buttons
Potentiometer
Type
Selects the DC voltage input of the
remote dimming bus.
28V, 5V
28V
Midpoint Day
Sets the day mode dimming
midpoint value used to tailor
dimming curves.
2 - 15
8
Midpoint Night
Sets the night mode dimming
midpoint value used to tailor
dimming curves.
2 - 15
8
Bezel
Luminance
Day Min
Sets the minimum day mode
luminance of the front panel button
backlights.
0 - 100, -1
(calibrated
defaults)
9
Bezel
Luminance
Day Max
Sets the maximum day mode
luminance of the front panel button
backlights.
0 - 100, -1
(calibrated
defaults)
100
Bezel
Luminance
Night Min
Sets the minimum day mode
luminance of the front panel button
backlights.
0 - 100, -1
(calibrated
defaults)
12
Bezel
Luminance
Night Max
Sets the maximum day mode
luminance of the front panel button
backlights.
0 - 100, -1
(calibrated
defaults)
22
OLED
Luminance
Day Min
Sets the minimum day mode
luminance of the OLED Screen.
0 - 100, -1
(calibrated
defaults)
27
OLED
Luminance
Day Max
Sets the maximum day mode
luminance of the front OLED Screen.
0 - 100, -1
(calibrated
defaults)
100
OLED
Luminance
Night Min
Sets the minimum night mode
luminance of the OLED Screen.
0 - 100, -1
(calibrated
defaults)
3
OLED
Luminance
Night Max
Sets the maximum night mode
luminance of the front OLED Screen.
0 - 100, -1
(calibrated
defaults)
20
Potentiometer
5V Min
Sets the minimum value expected
from the 5V dimming bus input (if
configured).
0 - 5000
0
Potentiometer
5V Max
Sets the maximum value expected
from the 5V dimming bus input (if
configured).
0 - 5000
5000
Potentiometer
28V Min
Sets the minimum value expected
from the 28V dimming bus input (if
configured).
0 - 28000
0
