Chapter 8 SYSTEM CONFIGURATION
8 - 8
8.4.1.2.5 DELETE LIBRARY
The DELETE LIBRARY function allows the operator to delete a protocol library. The library
to be deleted must be empty, that is, any protocols in the library must first have been
deleted.
If the pump displays ▲ ▼ SELECT LIBRARY, press ▲ or ▼ as necessary to select the
library to be deleted, and press CONFIRM to complete the selection.
The pump prompts the operator to confirm the deletion by displaying DELETE <library-
name>. N is displayed in the syringe manufacturer field. To delete the protocol press ▲ or
▼ to change the N to Y and press CONFIRM. The pump displays UPDATING.
NOTE
To skip deletion, confirm a N response. The pump returns to the ▲ ▼
SELECT LIBRARY prompt.
CAUTION
To prevent corruption of the configuration data, do not turn off the
pump while UPDATING is being displayed.
8.4.1.2.6 CREATE PROTOCOL
The CREATE PROTOCOL function allows the operator to add a new protocol to a protocol
library.
If the pump displays ▲ ▼ SELECT LIBRARY, press ▲ or ▼ as necessary to select the
library to which the protocol is to be added, and press CONFIRM to complete the selection.
Once a protocol has been selected, the pump displays NAME. Line 2 of the text display is
blank. Enter a name that is not already assigned to another protocol within the same
library. Press CONFIRM to complete the protocol name entry.
Next, the pump displays SELECT MODE ▲ ▼. Press ▲ or ▼ to select an infusion mode
to be assigned to the protocol, and press CONFIRM to complete mode selection.
NOTES
The pump offers an ALL MODES selection. If this selection is chosen,
all infusion modes will be available when the protocol is selected
during normal programming.
If ALL MODES, SINGLE DOSE, MANUAL SCHEDULE, AUTO
SCHEDULE or CUSTOM DILUTION is selected when CONFIRM is
pressed, no further settings are allowed for the protocol. If any
