102 pro+ Surface Instruction for Use (209196 REV 8)
Specifications
Conducted RF
IEC 61000-4-6
3 V
0.15 MHz - 80 MHz
6 V in ISM bands
between 0.15 MHz
and 80 MHz
80% AM at
1 kHz
3 V
0.15 MHz - 80 MHz
6 V in ISM bands
between 0.15 MHz
and 80 MHz
80% AM at
1 kHz
Field strengths from
fixed RF transmitters, as
determined by an
electromagnetic site
survey
a
, should be less
than the compliance
level in each frequency
range.
Interference may occur
in the vicinity of
equipment marked with
this symbol.
Radiated RF IEC
61000-4-3
3 V/m
80 MHz to 2.7 GHz
80% AM at
1 kHz
10 V/m
80 MHz to 2.7 GHz
80% AM at
1 kHz
NOTES:
• These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
•U
T
is the AC mains voltage prior to application of the test level.
a. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the pro+ surface is used
exceeds the applicable RF compliance level above, the pro+ surface should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be
necessary, such as reorienting or relocating the pro+ surface.
Guidance and Manufacturer's Declaration -
Electromagnetic Immunity
The pro+ surface is intended for use in the electromagnetic environment specified below.
The customer or the user should make sure it is used in such an environment.
Immunity Test
IEC 60601
Test Level
Compliance
Level
Electromagnetic
Environment—
Guidance
