biosystems BA 400 - Page 124

REAGENT CONTROL
Pipetting resolution
1 mL
Level detection Yes
Washing of tip Interior and exterior
Vertical collision detector Yes
ermostatted tip Yes
REACTION ROTOR
Minimum reaction volume 200 μL
Maximum reaction volume 600 μL
Number of cuvettes 120
Cuvette material UV methacrylate
Type of incubation Dry
Fixed dispensing time for 2nd reagent 5 min (xed)
Reaction cuvette temperature 37 °C
Temperature accuracy ±0.2° C
Temperature stability ±0.1° C
Stirrers 2
CUVETTE WASHING SYSTEM
Number of washing system tips 7
Number of tips with washing solution 2
Rinsing with water 3
Drying 2
Washing volume 711 μL
Washing solution consumption 1.42 mL/cycle
OPTICAL SYSTEM
Light source LED+Hard Coating Filter
No. of wavelengths 8
Wavelengths 340 – 405 – 505 – 535 – 560 – 600 – 635 – 670
nm
Filter band width 10 nm ± 2 nm
Wavelength accuracy ± 2 nm
Photometric range -0.2 A to 3.5 A
Internal resolution 0.0001
Detector Principal photodiode + reference photodiode
Measurement precision (for 340nm, 405nm and
505nm)
CV < 1 % at 0.1 A
CV < 0.1 % at 2 A
ISE MODULE (optional)
Type of sample Serum, Plasma or Urine
Type of electrode Na
+
, K
+
, Cl
-
. Li
+
(optional)
Service Manual
124
