8.4.1 Inhibit Mode
Receive an external input signal that controls the output state.
Default: O
To set Inhibit Mode:
1. Assign the inhibit In function to pin 3 by:
Press the button then use the soft key to select Utilities > I/O Cong > Digital I/O > Pin 3 > Inhibit
In.
2. Select Inhibit Mode: Press the button then use the soft key to select Utilities > I/O Cong > Digital I/O
> Inhibit Mode.
3. Select one of the following modes:
Note:
The following modes are only available for pin 3.
O
The inhibit input is ignored.
Latched
A logic-true transition signal will disable the power supply. The output will remain disabled.
Live
Power supply output follows the state of the inhibit signal. If the inhibit signal is true the output is disabled. When it is
false the output is enabled.
