Battery Charge Function 40
6.1.5 I End
Set a current limit value to interprertrated as the stop charging value of the battery.
– Use the numeric keypad or the rotary knob to enter or adjust the I End value.
– Press the to set the I End value.
6.1.6 End Delay
Set a delay to the battery charging function once the desired parameters have been readched.
Press the button then use the soft key to select List Battery > Batt Test Setup > Charge Test > End
Delay.
– Use the numeric keypad or the rotary knob to enter or adjust the end delay time.
– Press the to set the end delay time.
6.2 Battery Test Settings
6.2.1 Sampling Time
Set a time duration for the charging function.
Press the button then use the soft key to select List Battery > Batt Test Setup > Batt Test Settings >
Sampling Time.
Use the numeric keypad or rotary motor to select the sampling time. Press to assign the selected value. (.5s to
300s)
6.2.2 A-h On/O
Press the button then use the soft key to select List Battery > Batt Test Setup > Batt Test Settings >
A-h On/O.
Press the corresponding softkey to toggle the recording of AH.
6.2.3 W-h On/O
Press the button then use the soft key to select List Battery > Batt Test Setup > Batt Test Settings >
W-h On/O
Press the corresponding softkey to toggle the recording of WH.
