Data Logger 47
7.2.5 Status Code
Press the button then use the soft key to select Data logger > Status Code.
Toggle to enable/disable status code.
Enabled Status Code will record all codes reported. See 7.4 for an example.
In gure 7.4 the code 0x0001 is returned. This indicates OVP has been triggered.
Table 7.2 denes each code.
Code Description
0x0001 Over Voltage Protection Triggered
0x0002 Over Current Protection Triggered
0x0004 Over Temperature Protection Triggered
0x0008 Sense not connected
Table 7.2 Status Code
7.2.6 Trigger Source
Press the button then use the soft key to select Data logger > Trigger Source.
Datalog can be triggered in three ways: Manual, Digital IO, and Remote.
• Manual: Select to use manual trigger. The trigger softkey will be available as Datalog Start/Stop. See section 7.2.7
• Digital IO: Select to use the digital I/O pins to receive a trigger. To assign a function to a pin see section8.4.1.
• Remote: Select to receive a trigger from a remote interface.
Note:
For Digital IO and Remote the rst trigger will turn Data log on. A second trigger will begin
data recording. will be displayed on the top right when data is being logged. See 7.2.7
7.2.7 Datalog Start/Stop
Press the button then use the soft key to select Data logger > Datalog Start/Stop. Toggle to turn datalog
On/O.
will be displayed on the top right when data logger is on but not recording.
The command INIT:IMM:DLOG will turn on data logger.
For Digital IO press Datalog Start/Stop to turn data logger on.
will be displayed on the top right when data logger is recording.
The command TRIG:DLOG:IMM will begin the recording.
For Digital IO an input high signal to the set pin will turn data logger on.
If Trigger Source is set to manual pressing Datalog Start/Stop will start/stop recording without a second signal.
