Calibration Adjustment Procedure 70
11.1 Voltage Calibration Adjustment
For the voltage calibration procedure a precise DMM will be needed.
To adjust the voltage calibration:
1. Enter the Calibration Menu
• Press the button, then use the soft key to select Utilities > Test/Admin > Security.
Use the numeric keypad to enter security code. See the subsection Security. Press the button to enter
the security menu.
2. Use the softkeys to select Voltage.
3. Connect the DMM’s voltage input to the power supply’s binding post.
4. Use the softkey to select Start.
5. Use the numeric keypad to enter the measured voltage. Press the button to congure the point.
6. Repeat step 6 for the remaining calibration points.
7. Upon entering the last calibration point value the display will return to the select parameter calibration menu.
