Calibration Adjustment Procedure 72
11.3 OVP Calibration Adjustment
For the over voltage protection calibration the instrument’s voltage must be calibrated.
To adjust the OVP calibration:
1. Enter the Calibration Menu
• Press the button, then use the soft key to select Utilities > Test/Admin > Security.
Use the numeric keypad to enter security code. See the subsection Security. Press the button to enter the
security menu.
2. Use the softkeys to select OVP.
3. Connect the DMM’s voltage input to the power supply’s binding.
4. Use the softkey to select Start.
5. Calibration State will show as Busy. After a few seconds the calibration will be adjusted on its own.
6. Upon calibration the display will return to the select parameter calibration menu.
